Today Super Micro Computer Inc. launched a new generation of single processor platforms, X11 generation UP systems. Supermicro states that this new generation of products will raise the bar of performance and efficiency on what single processor platforms can do. Today’s announcement delivers the industry’s broadest range of workstations, long-life embedded solutions, and motherboard platforms supporting the new Intel Xeon Processor E3-1200 v5 Family (formally known as Skylake-S).
Supermicro’s X11 generation UP systems fit a wide range of use-cases including embedded server and security appliances, Cloud computing, web hosting, and network appliances. The new solutions support DDR4 memory, USB 3.1, M.2, Dual 10GBase-T and Quad Gigabit Ethernet LAN ports, IPMI 2.0, up to 7x PCI-E 3.0 x16 slots with Supermicro WIO (Wide I/O) flexible expansion slot capability, SATA DOM (Disk on Module) support.
New X11 solutions include:
- Workstation (SYS-5039A-IL) – CAD/CAM/CAE, Digital Imaging, Entry-Level Workstation, Medical Applications, Oil & Gas, Simulation & Automation. Supports Single Socket Intel Xeon processor E3-1200 v5 family, Intel 6th Gen Core i7/i5/i3 series processors, 4x 3.5" internal SATA HDD Bays, 90° rotatable HDD cage design, 4x 2.5" internal SATA HDD Bays (opt.), 2x PCI-E 3.0 x16, 2x PCI-E 3.0 x1 (in x4), and 2x PCI 32-bit slots, up to 64GB DDR4 2133MHz ECC UDIMMs in 4 sockets, Dual GbE LAN ports (1 via Intel i219LM + 1 via Intel i210-AT), 8x SATA3 (6Gbps) from Intel C236; RAID 0, 1, 5, 10, 6x USB 3.0 (2 rear, 4 via headers), 8x USB 2.0 (2 rear, 6 via headers), 2x USB 3.1 (rear), Audio: RealTek ALC888S HD Audio; Video: Aspeed AST2400, 500W High-efficiency Power Supply
- X11SAT / X11SAT-F (ATX, 12" x 9.6") supports single socket Intel Xeon processor E3-1200 v5 family, Intel 6th Gen Core i7/i5/i3 series processors, vPro AMT or IPMI 2.0, up to 64GB DDR4 2133MHz ECC UDIMMs in 4 sockets, 6x SATA3 (6Gbps) via PCH; RAID 0, 1, 5, 10, 1x PCIe M.2 (PCIe x4, 2260/2280), 3x PCI-E 3.0 x16, 1x PCI-E 3.0 x1 (in x4), 1x 5V PCI 32-bit slots, 2x GbE LAN (Intel i210-AT + Intel i219LM/V), 1x COM, 1x DVI – D, 1x DP (DisplayPort), 1x HDMI, ALC 888S HD Audio, 1x VGA for IPMI only (X11SAT-F), 2x SuperDOM w/ built-in power; TPM 1.2 header, 6x USB 3.0 (2 rear, 4 via headers), 6x USB 2.0 (2 rear, 4 via headers), 1x USB 3.1 (10Gbps) Type C ports (rear, share w/ Thunderbolt & DP)
- X11SAE (ATX, 12" x 9.6") supports single socket Intel Xeon processor E3-1200 v5 family, Intel 6th Gen Core i7/i5/i3 series processors, vPro AMT, up to 64GB DDR4 2133MHz ECC UDIMMs in 4 sockets, 8x SATA3 (6Gbps) via PCH; RAID 0, 1, 5, 10, 1x PCIe M.2 (PCIe x4, 2242/2260/2280), 2x PCI-E 3.0 x16, 3x PCI-E 3.0 x1, 2x 5V PCI 32-bit slots, 2x GbE LAN (Intel i210-AT + Intel i219LM), 2x COM, 1x DVI – D, 1x DP (DisplayPort), 1x HDMI, ALC 888S HD Audio, 2x SuperDOM w/ built-in power; TPM 1.2 header, 6x USB 3.0 (2 rear, 4 via headers), 8x USB 2.0 (2 rear, 6 via headers), 2x USB 3.1 (10Gbps) Type C ports
- X11SAE-F (ATX, 12" x 9.6") supports single socket Intel Xeon processor E3-1200 v5 family, Intel 6th Gen Core i7/i5/i3 series processors, up to 64GB DDR4 2133MHz ECC UDIMMs in 4 sockets, 8x SATA3 (6Gbps) via PCH; RAID 0, 1, 5, 10, 1x PCIe M.2 (PCIe x4, 2242/2260/2280), 2x PCI-E 3.0 x16, 2x PCI-E 3.0 x1, 2x 5V PCI 32-bit slots, 2x GbE LAN (Intel i210-AT + Intel i219LM), 2x COM, 1x DVI – D, 1x DP (DisplayPort), 1x HDMI, ALC 888S HD Audio, 1x VGA for IPMI only (Intel i210-AT GbE LAN share with IPMI), 2x SuperDOM w/ built-in power; TPM 1.2 header, 6x USB 3.0 (2 rear, 4 via headers), 6x USB 2.0 (2 rear, 4 via headers), 2x USB 3.1 (10Gbps) Type C ports
- X11SAE-M (micro ATX, 9.6" x 9.6") supports single socket Intel Xeon processor E3-1200 v5 family, Intel 6th Gen Core i7/i5/i3 series processors, vPro AMT, up to 64GB DDR4 2133MHz ECC UDIMMs in 4 sockets, 8x SATA3 (6Gbps) via PCH; RAID 0, 1, 5, 10, 1x PCIe M.2 (PCIe x4, 2242/2260/2280/22110), 1x PCI-E 3.0 x16, 1x PCI-E 3.0 x4, 1x 5V PCI 32-bit slots, 2x GbE LAN (Intel i210-AT + Intel i219LM), 1x COM, 1x DVI – D, 1x DP (DisplayPort), 1x HDMI, ALC 888S HD Audio, 2x SuperDOM w/ built-in power; TPM 1.2 header, 6x USB 3.0 (2 rear, 4 via headers), 6x USB 2.0 (2 rear, 4 via headers), 2x USB 3.1 (10Gbps) Type C ports
- X11SSZ-TLN4F / X11SSZ-F (microATX, 9.6" x 9.6") supports single socket Intel Xeon processor E3-1200 v5 family, Intel 6th Gen Core i3 series processor, Intel Celeron and Intel Pentium processors, vPro AMT, up to 64GB DDR4 2133MHz ECC UDIMMs in 4 sockets, 4x SATA3 (6Gbps) via PCH; RAID 0, 1, 5, 10, 1x PCI-E 3.0 x16 (in x16) and 2x PCI-E 3.0 x4 (in x8), I/O: 2x 10GbE (-TLN4F)/2x GbE (-F), 1x VGA, 2x COM, Video: 1x HDMI, 1x DP, 1x DVI-I/D, 1x Intel HD Graphics, Audio: RealTek ALC 888S High Definition Audio, Integrated IPMI 2.0 and KVM with Dedicated LAN (-F), 1x SuperDOM w/ built-in power; TPM 1.2 header, 4x USB 3.0 (2 rear, 2 via header), 9x USB 2.0 (4 rear, 4 via headers, 1 Type A), 8-pin 12V DC power option
