Supermicro to Unveil New Compact Intel Xeon Processor D-Based Solutions

This week, Super Micro Computer will demonstrate the latest additions to their Embedded Building Block Solutions portfolio at Embedded World in Nuremberg, Germany, highlighted by an expanded range of compact X10SDV motherboards. These motherboards will now extend top-end performance, including support for the new 65W 16-core Intel Xeon processor D-1587 on the X10SDV-7TP8F. They will also debut low power solutions that support the 25W 2-core Intel Pentium processor D-1508 on the X10SDV-2C-7TP4F featured in the new 1U 12x 3.5” hot-swap HDD Cold Storage solution SSG-5018D2-AR12L.

This week, Super Micro Computer will demonstrate the latest additions to their Embedded Building Block Solutions portfolio at Embedded World in Nuremberg, Germany, highlighted by an expanded range of compact X10SDV motherboards. These motherboards will now extend top-end performance, including support for the new 65W 16-core Intel Xeon processor D-1587 on the X10SDV-7TP8F. They will also debut low power solutions that support the 25W 2-core Intel Pentium processor D-1508 on the X10SDV-2C-7TP4F featured in the new 1U 12x 3.5” hot-swap HDD Cold Storage solution SSG-5018D2-AR12L.

The new series of compact X10SDV boards will also include support for the Intel Xeon processor D-1500 family 8-core (X10SDV-7TP4F) in 1U warm storage SSG-5018D8-AR12L, 4-core (X10SDV-4C-7TP4F), and 2-core (X10SDV-2C-7TP4F) in 1U cold storage SSG-5018D4-AR12L. Supermicro adds that, when combined with embedded optimized SuperChassis SC504/505/510/721 and SC514/515/813, enterprises will be able move from new applications from cold, warm and hot storage to converged infrastructure, which is ideal for network/datacenter edge to cloud solutions.

In addition, Supermicro will demonstrate their new compact 1U short-depth SuperServers, Mini-Tower and Box PC systems, ultra low-power Edge-to-Cloud mesh network IoT Gateway System (SYS-E100-8Q) powered by a 2.2W Intel Quark SoC X1021, single (UP) and dual processor Intel Xeon processor-based motherboards and SuperChassis solutions.

The following is a complete list of Supermicro Embedded Server, Storage and Networking Building Block Solutions that will be showcased at Embedded World:

• New 2016 X10SDV Series Motherboards and Systems supporting Intel Xeon Processor D-1500 Family
  • X10SDV-16C(+)-TLN4F – Mini-ITX, Intel Xeon processor D-1587 SoC 16-core, 65W (+ w/ Fan), Dual 10GbE/1GbE, M.2, up to 128GB DDR4 RDIMM, Optimized Chassis SC721, SC505/504
  • X10SDV-12C-TLN4F – Mini-ITX, Intel Xeon processor D-1557 SoC 12-core, 45W, Dual 10GbE/1GbE, M.2, up to 128GB DDR4 RDIMM, Optimized Chassis SC505/504
  • X10SDV-6C(+)-TLN4F – Mini-ITX, Intel Xeon processor D-1528 SoC 6-core, 35W (+ w/ Fan), Dual 10GbE/1GbE, M.2, up to 128GB DDR4 RDIMM, Optimized Chassis SC721, SC505/504
  • X10SDV-4C-TLN4F – Mini-ITX, Intel Xeon processor D-1518 SoC 4-core, 35W, Dual 10GbE/1GbE, M.2, up to 128GB DDR4 RDIMM, Optimized Chassis, SC505/504
  • X10SDV-7TP8F (SYS-1018D-FRN8T) – Flex ATX, Intel Xeon processor D-1587 SoC 16-core, 65W, Dual 10GbE SFP+, 6x 1GbE LAN Ports, up to 22x SATA devices, Optimized Chassis: SC515R
  • X10SDV-TP8F (SYS-5018D-FN8T) – Flex ATX, Intel Xeon processor D-1518 SoC 4-core, 35W, Dual 10GbE SFP+, 6x 1GbE LAN Ports, up to 22x SATA devices, Optimized Chassis: SC505
  • X10SDV-7TP4F (SSG-5018D8-AR12L) – Flex ATX, Intel Xeon processor D-1537 SoC 8-core, 35W, Dual 10GbE SFP+, 2x 1GbE LAN Ports, Optimized Chassis: SC801L
  • X10SDV-4C-7TP4F (SSG-5018D4-AR12L) – Flex ATX, Intel Xeon processor D-1518 SoC 4-core, 35W, Dual 10GbE SFP+, 2x 1GbE LAN Ports, up to 22x SATA devices, Optimized Chassis: SC801L
  • X10SDV-2C-7TP4F (SSG-5018D2-AR12L) – Flex ATX, Intel Pentium processor D-1508 SoC 2-core, 25W, Dual 10GbE SFP+, 2x 1GbE LAN Ports, up to 22x SATA devices, Optimized Chassis: SC801L
  • X10SDV-2C-TP8F – Flex ATX, Intel Pentium processor D-1508 SoC 2-core, 25W, Dual 10GbE SFP+, 6x 1GbE LAN Ports
  • X10SDV-4C+-TP4F – Flex ATX, Intel Xeon processor D-1518 SoC 4-core, 35W (w/ Fan), Dual 10GbE SFP+, 2x 1GbE LAN Ports
  • X10SDV-2C-TP4F (SYS-5018D-LN4T) – Flex ATX, Intel Pentium processor D-1508 SoC 2-core, 25W, Dual 10GbE SFP+, 2x 1GbE LAN Ports, Optimized Chassis: SC504
• Compact Servers
  • SYS-E100-8Q – IoT Wireless Gateway. Compact, Ultra Low-Power, Fanless Edge to Cloud Mesh Network Device. Supports 2.2W Intel Quark X1021 SoC
  • SYS-5029S-TN2 – Space-efficient, Mini-Tower for Cloud/NAS applications in SOHO and Corporate environments. Supports 6th Gen Intel Core i7, Core i5, Core i3, Pentium, Celeron processors, Intel Q170 Chipset
  • SYS-5018A-FTN4 – 1U Short-Depth, Front I/O server for gateway, file-sharing, security appliances. Supports Intel Atom processor C2758 (20W 8-core)
  • SYS-E200-9B – Compact 1U Mini ITX BOX PC for digital signage, kiosk applications. Supports Intel Pentium N3700 (6W 4-Core)
  • SYS-5018A-TN7B – Compact Network Security Server with 3-pair LAN bypass capability. Supports Intel Atom processor C2758 (20W 8-core)
  • SYS-1018L-MP – Compact System optimized for Security Appliance, Surveillance, Digital Signage, Indoor Kiosk- Video processing, streaming. Supports 4th Gen Intel Core i7, Core i5, Core i3, Pentium, and Celeron processors, Intel H81 Chipset
  • SYS-1019S-M2 – 1U Rear I/O server optimized for Military, Industrial Automation, Medical application servers. Supports 6th Gen Intel Core i7, Core i5, Core i3, Pentium, Celeron processors, Intel Q170 Chipset

• Uni-Processor (UP) Motherboards
  • A1SQN – Ultra Low-Power, Compact E100 (4.1" x 4.0") IoT Gateway device. Supports Intel Quark SoC (2.2W), 512MB DDR3 ECC memory onboard, 2x Mini-PCI-E slots, 1x ZigBee module socket, TPM 1.2, 2x 10/100Mbps LAN
  • Compact Low-Power Intel Atom processor C2558/C2758 SoC, Micro ATX
  • § A1SRM-LN7F-2758F, A1SRM-LN5F-2358 (communications 3 pair LAN bypass); A1SRM-2558F/-2758F, A1SRi-2558F/-2758F (communications Intel Quick Assist Technology)
  • X11SBA-F/-LN4F – Mini-ITX supports Intel Pentium N3700 (6W, 4-core), Intel HD Graphics with HDMI, Display port, and VGA, Quad 1GbE LAN (dual for -F) with IPMI
  • X11SSV-Q – Mini-ITX supports 6th Gen Intel Core i7, Core i5, Core i3, Pentium, Celeron processors, Intel Processor Graphics with DisplayPort, HDMI, and DVI-I for 3 Independent Displays, AMT 11.0, vPro
  • X11SSQ – Micro ATX supports 6th Gen Intel Core i7, Core i5, Core i3, Pentium, Celeron processors, Intel Processor Graphics with DisplayPort, HDMI, and DVI-D for 3 Independent Displays, AMT 11.0, vPro
  • X11SSZ-QF – Micro ATX supports 6th Gen Intel Core i7, Core i5, Core i3, Intel Pentium, Celeron processors, Intel Processor Graphics with 2 DisplayPorts and 1 DVI-I for 3 Independent Displays, AMT 11.0, vPro, IPMI, 12V DC
  • X11SSZ-TLN4F – Micro ATX supports Intel Xeon processor E3-1200 v5, 6th Gen Intel Core i7, Core i5, Core i3, Pentium, Celeron processors, Intel Processor Graphics with 2 DisplayPorts and 1 DVI-I for 3 Independent Displays, Dual 10GbE LAN ports , AMT 11.0, vPro, and IPMI
  • X11SAE-F – ATX supports Intel Xeon E3-1200 v5, 6th Gen Intel Core i7, Core i5, Core i3, Pentium, Celeron processors, Intel Processor Graphics with Display Port, HDMI, and DVI-D, 3 Independent Displays, AMT 11.0, vPro, and IPMI
  • X9SKV-1125 – Intel Xeon processor E3-1125C, 40W, 2.0GHz. 8M, (formerly codenamed Gladden) / -1105(Intel Xeon processor E3-1105C v2, 25W, 1.8GHz. 8M) / -B915 (Intel Pentium processor B915C, 15W, 1.5GHz. 3M); Flex ATX (9.0" x 7.2"), Intel Communication Chipset 8903, quad ports programmable LAN bypass
• Dual Processor (DP) Motherboards supporting Intel Xeon Processor E5-2600 v3
  • X10DRi/-T4+ – E-ATX, up to 1TB ECC DDR4 2133MHz in 16x DIMM slots, Intel X540 Dual port 10GBASE-T LAN
  • X10DRH-iT – E-ATX, up to 1TB ECC DDR4 2133MHz in 16x DIMM slots, 10x SATA3 (6Gbps) ports w/ Intel C612 controller; RAID 0, 1, 5, 10, Intel X540 Dual port 10GBASE-T LAN
  • X10DRL-i – ATX, up to 512GB ECC DDR4 2133MHz in 8x DIMM slots, 10x SATA3 (6Gbps); RAID 0, 1, 5, 10
  • X10DRL-CT – ATX, up to 512GB ECC DDR4 2133MHz in 8x DIMM slots, 8x SAS3 (12Gbps) via LSI 3108; HW RAID 0, 1, 5, 6, 10, 50, 60; 6x SATA3 (6Gbps); RAID 0, 1, 5, 10
  • X10DRW-i(T) – WIO, up to 1TB ECC DDR4 2133MHz in 16x DIMM slots, 10x SATA3 (6Gbps); RAID 0, 1, 5, 10, Flexible I/O via WIO Riser Card, 1x PCI-E 3.0 x32, 1x PCI-E 3.0 x16
  • X10DDW-i – WIO, up to 1TB ECC DDR4 2133MHz in 16x DIMM slots, 1x PCI-E 3.0 x32 Left riser slot, 1x PCI-E 3.0 x8 Right riser slot, 1x PCI-E 3.0 x8 for Add-On-Module, Intel i350 Dual port Gigabit Ethernet, 10x SATA3 (6Gbps); RAID 0, 1, 5, 10
• New SuperChassis
  • CSE-514-R400C – 1U short-depth rackmount chassis for UP/DP motherboards. 2x 2.5" Internal Drive Bays, 1x Full-height AOC expansion slot, 4x 40x56mm high-efficiency fans, 400W redundant power supplies
  • CSE-721TQ-250B – Compact Mini-Tower for Mini-ITX motherboards, 4x 3.5" Hot-Swap SATA HDD and 2x internal 2.5" SATA HDD (or 1x 2.5” HDD + slim DVD slot), 1x low profile expansion slot
  • CSE-101S – Slim, space saving 1U BOX PC for Mini-ITX form factor (7.68" x 7.68" x 1.75”), 1x 2.5" internal HDD support (design for 9.5mm thickness HDD), VESA/Wall-mount ready
  • CSE-504-203B – 1U short-depth rackmount chassis, 1x 3.5" Internal Drive Bay with 1x Half-height, Half-length PCI, or 2x 3.5" Internal Drive Bays, or 2x 2.5" Internal Drive Bays with 1x Full-height, Half-length PCI, or 4x 2.5" Internal Drive Bays

Supermicro Solutions based on Intel Xeon Processor E5 Family
